Did your flex circuit design fall short of expectations? Don’t worry; you’re not alone. Many designs face challenges during production, but that doesn’t mean all is lost. At Flexdude, we specialize in identifying and correcting the issues in your flex circuit designs, ensuring that your next batch of parts works flawlessly.
We start by thoroughly reviewing your CAD files, examining every detail to understand the design’s intent and where it may have gone wrong.
Our engineers use advanced diagnostic tools and their extensive experience to identify the root causes of the failure. This can include issues with impedance control, line length matching, current capacity, and more.
Once the problems are identified, we correct the flex circuit design as needed. This could involve redesigning certain elements, adjusting parameters, or adding essential features that were previously missing.
We rigorously test the revised design using simulations to ensure it meets all functional requirements and performs reliably under various conditions.
After confirming that the design works, we update all relevant documentation, including Gerber files, drill files, and other necessary files for fabrication and assembly.
We provide ongoing support to ensure that the revised design meets your expectations during production. Feel free to contact our team if you have any questions or if further adjustments need to be made.
Don’t let a lousy design derail your project. Contact Flex Circuit Design Company today and let our experts turn your flex circuit failures into successes. Please send us your CAD files, and let’s get started on making your design work!
Flex circuits are unique—they are neither purely mechanical nor purely electrical. Many flexible Printed Circuit Board (PCB) designers are available, but very few know the intricacies of flex circuits!
